High Temperature, Heat Resistant & Radiant Heat Reflective
Aluminum Coated Fiberglass Sleeve
Aluminum Coated Fiberglass Sleeve
Radiant
Heat Reflective Sleeve
Heat Reflective Sleeve
High temperature, heat resistant and radiant heat reflective sleeve can be used to protect industrial wires, cables, hoses (hydraulics), piping and tubing from radiant heat sources such as glowing steel slab, liquid metal pour stream, infrared heaters and other similar sources. This type of sleeve is also popular for automotive wiring protection under-hood.
Sleeves with different base materials are available: thin fiberglass or high bulk fiberglass. Sewn sleeve is available fabricated from 21oz coated fiberglass fabric.
An aluminum foil or aluminum-mylar-aluminum coating over fiberglass is available. These materials can reflect up to 95% of the radiant energy that hits its surface, keeping the underlying cables and hoses cool.
Sleeves with different base materials are available: thin fiberglass or high bulk fiberglass. Sewn sleeve is available fabricated from 21oz coated fiberglass fabric.
An aluminum foil or aluminum-mylar-aluminum coating over fiberglass is available. These materials can reflect up to 95% of the radiant energy that hits its surface, keeping the underlying cables and hoses cool.
Large Diameter InfraFlectä Radiant
Heat Reflective Sleeve
Heat Reflective Sleeve
Sewn Sleeve from 21oz coated fabric
Split sleeve with adhesive closure strip
Continuous closed Sleeve
Closed Sleeve: High Bulk Convoluted
Wrap with adhesive strip
Part Number
S-FG-AL-ACL
S-FG-AL-ACL
Part Number
S-FG-AL
S-FG-AL
Part Number
S-FG-AL-C
S-FG-AL-C
Part Number
S-FG-AL-TACL
S-FG-AL-TACL
Part Number
S-FG-AL-SS
S-FG-AL-SS
• Protects from radiant heat by reflecting 95% of the heat that
contacts its surface.
• Split sleeve fiberglass with aluminum heat reflecting coating.
• Adhesive strip closure.
• Cuts cleanly.
• Protects wiring, cables and hoses from radiant and convective heat.
• Excellent automotive under-hood protection.
• .042" wall thickness - 4 foot lengths.
• 1/4" minimum ID - 2" maximum ID in 9 sizes.
contacts its surface.
• Split sleeve fiberglass with aluminum heat reflecting coating.
• Adhesive strip closure.
• Cuts cleanly.
• Protects wiring, cables and hoses from radiant and convective heat.
• Excellent automotive under-hood protection.
• .042" wall thickness - 4 foot lengths.
• 1/4" minimum ID - 2" maximum ID in 9 sizes.
• Protects from radiant heat by reflecting 95% of the heat that
contacts its surface.
• Cuts cleanly.
• Protects wiring, cables and hoses from radiant and convective heat.
• Excellent automotive under-hood protection
• .025" wall thickness - 50, 100 and 250 foot lengths.
• 1/2" minimum ID - 2.5" maximum ID in 10 sizes.
contacts its surface.
• Cuts cleanly.
• Protects wiring, cables and hoses from radiant and convective heat.
• Excellent automotive under-hood protection
• .025" wall thickness - 50, 100 and 250 foot lengths.
• 1/2" minimum ID - 2.5" maximum ID in 10 sizes.
• Protects from radiant heat by reflecting 95% of the heat that
contacts its surface.
• High bulk fiberglass for higher thermal insulation value.
• Cuts cleanly.
• Protects wiring, cables and hoses from radiant and convective heat.
• Excellent automotive under-hood protection.
• .045" wall thickness - 4 foot lengths.
• 1/2" minimum ID - 1.25" maximum ID in 5 sizes.
contacts its surface.
• High bulk fiberglass for higher thermal insulation value.
• Cuts cleanly.
• Protects wiring, cables and hoses from radiant and convective heat.
• Excellent automotive under-hood protection.
• .045" wall thickness - 4 foot lengths.
• 1/2" minimum ID - 1.25" maximum ID in 5 sizes.
• Protects from radiant heat by reflecting 95% of the heat that
contacts its surface.
• Similar construction to S-FG-AL but in a tape that can be formed
into sleeves or spiral wrapped as a tape. Cuts cleanly.
• Protects wiring, cables and hoses from radiant and convective heat.
• Excellent automotive under-hood protection.
• .025" wall thickness - 50, 100 and 250 foot lengths.
• 1/2" minimum ID - 2.5" maximum ID in 10 sizes.
contacts its surface.
• Similar construction to S-FG-AL but in a tape that can be formed
into sleeves or spiral wrapped as a tape. Cuts cleanly.
• Protects wiring, cables and hoses from radiant and convective heat.
• Excellent automotive under-hood protection.
• .025" wall thickness - 50, 100 and 250 foot lengths.
• 1/2" minimum ID - 2.5" maximum ID in 10 sizes.
• Protects from radiant heat by reflecting 95% of the heat that
contacts its surface.
• Made from a 21oz aluminum foil coated fiberglass base fabric.
• Cuts cleanly with minimal fray.
• Protects wiring, cables and hoses from radiant and convective heat.
• Excellent automotive under-hood protection.
• .025" wall thickness - 50, 100 and 250 foot lengths.
• 1/2" minimum ID - 2.5" maximum ID in 10 sizes.
contacts its surface.
• Made from a 21oz aluminum foil coated fiberglass base fabric.
• Cuts cleanly with minimal fray.
• Protects wiring, cables and hoses from radiant and convective heat.
• Excellent automotive under-hood protection.
• .025" wall thickness - 50, 100 and 250 foot lengths.
• 1/2" minimum ID - 2.5" maximum ID in 10 sizes.
